General Description
| Built | P.T> Batamec Shipyard |
| Date of Built | 2010 |
| Port of Registry | Liberia |
| Signal Letters | D5FO9 |
| Ship ID | IMO no. 9571002 |
| Class Society | ABS |
| Type of Vessel | Anchor Handling and Tug Supply (AHTS) |
| Max Bollard Pull | 120 MT |
| Brake Horsepower | 10,800 |
| Max POB | 42 |
Principal Dimensions
| Meters | Feet | |
|---|---|---|
| Length Overall | 67 | 220’ |
| Breadth | 16 | 52’ |
| Depth | 7 | 23’ |
| Min. Operational Draft | 4.2m | |
| Summer Draft | 6.0m | |
| Deck Area | 420m2 / 4,520sqft | |
| Deck Strength | 10.0t /m2 | |
Tonnage
| Gross Tonnage | 2310.00 tons |
| Net Tonnage | 693.00 tons |
Engines
| Fuel | 700 liters / hour by engines (DP operation) |
| Main Engines | 2 x 4000kW Warttsila 8L32 |
| Generators |
Auxiliary - 2 x 590kW Caterpillar 3412DITA Shaft - 2 x 1520kW Leroy Somer LSA52,2 Emergency - 1 x84kW Caterpillar C4.4DITA |
| Propellers | 2 – 70” Diameter x 46” Pitch |
| Thrusters |
Bow - 2 x 600kW Wartsila LIPSTRONIC 7000 Stern - 1 x 600kW Wartsila LIPSTRONIC 7000 |
Life Saving Equipment
| Life rafts | 4 x 25 / 2 x 20 men |
| Life buoys |
2 x with light and smoke signal 2 x with light 4 x with buoyant lifelines |
| Fast rescue Boat | 6 pax inflatable DSB 5.1 SR/IRB c/w 26.5 kW Yanmar D36 Outboard Enginge |
| Safety Systems | Fire Detection, H2S Detection, Tilt Alarm, Engine Alarm, CO2 for engine room & Emergency Generator room |
Communication & Navigation Equipment
| VSAT with VOIP / Internet available | |
| Satellite phone | 2 x Furuno |
| GMDSS MF/HF/DSC | Samyung |
| Navtex | Furuno |
| EPIRB | McMurdo E5 SMARTFIND |
| SART | 2 x McmUrdo |
| Public Address | Standard Horizon |
| Vhf Radio | 2 x McMurdo |
Capacities
| Diesel Fuel Storage Capacity | 1,240,000 liters |
| Fresh Water Storage | 243,000 liters |
| Drill Water / Ballast | 760,000 liters |
